HPE SERVER DL360 GEN10 6226R/P24742-B21 (P24742-B21)

Lifecycle

• Obsolete Date 29-02-2024
• End of support date 31-10-2028

Specifications

• Expansion slots 2 PCIe 3.0, for detailed descriptions reference the QuickSpecs
• Memory, standard 32 GB (1 X 32 GB) RDIMM
• Memory type HPE DDR4 SmartMemory
• Infrastructure management HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); Optional- HPE iLO Advanced, and HPE OneView Advanced (require licenses)
• Network controller HPE Ethernet 10Gb 2-port 562FLR-T Adapter
• Number of processors 2, maximum depending on model
• Processor Name Intel® Xeon® Scalable 6226R (16 core, 2.9 GHz, 150W)
• Processor number 1 processor
• Weight 13.04 kg minimum, 16.27 kg maximum
• Security Optional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0
• NVDIMM rank N/A
• NVDIMM type N/A
• NVDIMM capacity N/A
• Warranty 3/3/3 – Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: http://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, refer to the HPE website at http://www.hpe.com/support
• Storage controller HPE Smart Array S100i
• Form factor 1U
• System fan features 5 standard hot plug fans
• Power supply type 1 HPE 800W Flex Slot Platinum hot-plug power supply
• Included hard drives None ship standard, 8 SFF drives supported
• Optical drive type None included
• Weight 28.74 lb minimum, 35.86 lb maximum
• Product Dimensions (imperial) 1.69 x 17.11 x 27.83 in
• Product Dimensions (metric) 4.29 x 43.46 x 70.7 cm
• Processor cache 22 MB L3
• Processor core available 16 core
• Processor speed 2.9 GHz
