Dell PowerEdge XR8720t
Run complete Cloud RAN and Open RAN DU workloads in a single server, with greater performance and efficiency in a compact, rugged design built for the next-generation network and edge deployments.
PowerEdge XR8720t
Run complete Cloud RAN and Open RAN DU workloads in a single server, with greater performance and efficiency in a compact, rugged design built for the next-generation network and edge deployments.
Key Features
2U server sled for XR8000 chassis
Run complete Cloud RAN and Open RAN DU workloads in a single server, with greater performance and efficiency in a compact, rugged design built for the next-generation network and edge deployments.
Specifications
| Processor | One Intel®Xeon®6 SoC processor HCC: Up to 40 cores XCC: up to 72cores |
| Operating System | Wind River SUSE Linux Enterprise Server/RT Canonical Ubuntu Server LTS Red Hat Enterprise Linux/RT |
| Memory | DIMM Speed Up to 6400 MT/s Memory Type RDIMM Memory Module Slots HCC: 4 DDR5 DIMM slots XCC: 8DDR5 DIMM slots Maximum RAM 384 GB with HCC processor 768 GBwith XCCprocessor |
| Storage | Internal Storage Up to three NVMe M.2 non-hot swappable drives, 5.76 TB max |
| Security | Cryptographically signed firmware Secure Boot Secure Erase Secured Component Verification (Hardware integrity check) Silicon Root of Trust System Lockdown (requires iDRAC Enterprise or Datacenter) TPM 2.0 FIPS, CC-TCG certified |
| Management | Embedded / At-the-Server iDRAC iDRAC Direct iDRAC RESTful API with Redfish iDRAC Service Module Tools Dell Repository Manager Dell System Update Enterprise Catalogs iDRAC RESTful API with Redfish IPMI RACADM CLI |
| Power Supplies | 1400 W -48 VDC (Reversed Air Flow), hot swap redundant Fans Two sets (4x fan module) Cabled fans |
| Ports | OCP Network Options Network optimized configuration: Up to two DSFF OCP NIC card 3.0: (8 x SFP 10/25 GbE ports per card) optional Embedded NIC Flexible configuration: 2 x QSFP 100 GbE ports Network optimized configuration: 8 x SFP 10/25 GbE ports Front Ports 1 x RJ45 Dedicated iDRAC Direct 1 x RJ45 dry port 1 x USB – A 3.0 compliant port 2 x SMA for ePPS input/output 1 x SMA for GNSS antenna (optional) 1 x UCB-C for system management 1 x Mini-DisplayPort |
| Slots | PCIe Flexible Configuration: Up to three PCIe slots (x16 connector) Slot 1: 1 x8 Gen5 Full Height Half Length Slot 2: 1 x8 Gen5 Full Height Half Length Slot 3: 1 x16 Gen5 Full Height Half Length |
| Chassis | XR8000r |
| Bezel | Security Bezel (optional) |
| Form Factor | 2U Sled |
| Dimensions & Weight | Height: 3.26″ (82.95 mm) Width: 7.27″ (184.8 mm) Depth: 16.97″ (431.13 mm) Weight: 17.15 lb (7.78 kg) |
| Rack Support | ReadyRails static B31 rails for 4-post and 2-post racks. (No support for CMA or SRB) |
| Recommended Support | Choose Dell ProSupport Plus or Dell ProSupport for premium hardware and software support. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region. For more information, visitwww.delltechnologies.com/Services. |
| Processor | One Intel®Xeon®6 SoC processor HCC: Up to 40 cores XCC: up to 72cores |
| Operating System | Wind River SUSE Linux Enterprise Server/RT Canonical Ubuntu Server LTS Red Hat Enterprise Linux/RT |
| Memory | DIMM Speed Up to 6400 MT/s Memory Type RDIMM Memory Module Slots HCC: 4 DDR5 DIMM slots XCC: 8DDR5 DIMM slots Maximum RAM 384 GB with HCC processor 768 GBwith XCCprocessor |
| Storage | Internal Storage Up to three NVMe M.2 non-hot swappable drives, 5.76 TB max |
| Security | Cryptographically signed firmware Secure Boot Secure Erase Secured Component Verification (Hardware integrity check) Silicon Root of Trust System Lockdown (requires iDRAC Enterprise or Datacenter) TPM 2.0 FIPS, CC-TCG certified |
| Management | Embedded / At-the-Server iDRAC iDRAC Direct iDRAC RESTful API with Redfish iDRAC Service Module Tools Dell Repository Manager Dell System Update Enterprise Catalogs iDRAC RESTful API with Redfish IPMI RACADM CLI |
| Power Supplies | 1400 W -48 VDC (Reversed Air Flow), hot swap redundant Fans Two sets (4x fan module) Cabled fans |
| Ports | OCP Network Options Network optimized configuration: Up to two DSFF OCP NIC card 3.0: (8 x SFP 10/25 GbE ports per card) optional Embedded NIC Flexible configuration: 2 x QSFP 100 GbE ports Network optimized configuration: 8 x SFP 10/25 GbE ports Front Ports 1 x RJ45 Dedicated iDRAC Direct 1 x RJ45 dry port 1 x USB – A 3.0 compliant port 2 x SMA for ePPS input/output 1 x SMA for GNSS antenna (optional) 1 x UCB-C for system management 1 x Mini-DisplayPort |
| Slots | PCIe Flexible Configuration: Up to three PCIe slots (x16 connector) Slot 1: 1 x8 Gen5 Full Height Half Length Slot 2: 1 x8 Gen5 Full Height Half Length Slot 3: 1 x16 Gen5 Full Height Half Length |
| Chassis | XR8000r |
| Bezel | Security Bezel (optional) |
| Form Factor | 2U Sled |
| Dimensions & Weight | Height: 3.26″ (82.95 mm) Width: 7.27″ (184.8 mm) Depth: 16.97″ (431.13 mm) Weight: 17.15 lb (7.78 kg) |
| Rack Support | ReadyRails static B31 rails for 4-post and 2-post racks. (No support for CMA or SRB) |
| Recommended Support | Choose Dell ProSupport Plus or Dell ProSupport for premium hardware and software support. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region. For more information, visitwww.delltechnologies.com/Services. |
