Dell PowerEdge R360
The 1U, single-socket PowerEdge R360 is an entry-level rack server for customers desiring versatility, affordability, and processing power.
PowerEdge R360
The 1U, single-socket PowerEdge R360 is an entry-level rack server for customers desiring versatility, affordability, and processing power.
Key Features
PowerEdge R360
• Intel® Pentium® G7400 3.7G• 1x 16GB, 5600MHz• 1x 2TB HD SATA• 1 yr Basic Support
Processing performance, GPU support
The 1U, single-socket PowerEdge R360 is an entry-level rack server for customers desiring versatility, affordability, and processing power.
Specifications
| Processor | One Intel®Xeon®6300 series processor or one Intel®Xeon®E-2400 series processor with up to 8 cores or One Intel®Pentium®G7400/ G7400T processor with 2 cores |
| Operating System | Canonical®Ubuntu®Server LTS Microsoft®Windows Server®with Hyper-V RedHat®Enterprise Linux SUSE®Linux Enterprise Server VMware®ESXi® |
| Chipset | Intel®C262 Chipset |
| Accelerators | NA |
| Memory | DIMM Speed Up to 4400 MT/s Memory Type ECC UDIMM Memory Module Slots 4 DDR5 DIMM slots Maximum RAM ECC UDIMM 128 GB |
| Storage | Front Bay Up to 4 x 3.5’’ SAS/SATA HDD/SSD, max 64 TB Up to 8 x 2.5’’ SAS/SATA HDD/SSD, max 61.44 TB Up to 6 x 2.5″ SAS/SATA HDD/SSD+2 x 2.5″ NVMe, max 61.44 TB Note: NVMe doesn’t support S160 or HW RAID configuration. Mid Bay NA Rear Bay NA |
| Storage Controllers | Internal Controllers HBA355i Adpt, PERC H355 Adpt, PERC H755 Adpt, HBA355i front, H355 front, H755 front External Controllers HBA355e Adpt Software RAID S160 Internal Boot Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs USB |
| Security | Cryptographically signed firmware Data at Rest Encryption (SEDs with local or external key mgmt) Secure Boot Secure Erase Secured-core server Secured Component Verification (Hardware integrity check) Silicon Root of Trust System Lockdown (requires iDRAC9 Enterprise or Datacenter) TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ |
| Management | Embedded / At-the-Server: iDRAC9 iDRAC Direct iDRAC RESTful API with Redfish iDRAC Service Module Consoles: OpenManage Enterprise OpenManage Power Manager plugin OpenManage Service plugin OpenManage Update Manager plugin CloudIQ for PowerEdge plug in OpenManage Enterprise Integration for VMware®vCenter™ OpenManage Integration for Microsoft®System Center OpenManage Integration with Windows Admin Center Mobility: OpenManage Mobile Tools: Dell Repository Manager Dell System Update Enterprise Catalogs iDRAC RESTful API with Redfish IPMI RACADM CLI OpenManage Integrations: BMC Truesight Microsoft®System Center OpenManage Integration with ServiceNow RedHat®Ansible®Modules Terraform Providers VMware®vCenter™ and vRealize Operations Manager |
| Power Supplies | 600 W Platinum 100 — 240 VAC or 240 VDC, hot swap redundant 700 W Titanium 200 — 240 VAC or 240 VDC, hot swap redundant |
| Ports | Network Options 2 x 1GbE LOM Front Ports 2 x 1GbE LOM 1 x iDRAC Direct (Micro-AB USB) port 1 x USB 2.0 Rear Ports 1 x Dedicated iDRAC Ethernet port 1 x USB 2.0 1 x USB 3.2 Gen1 1 x VGA 1 x Serial Internal Ports 1 x USB 3.2 Gen1 |
| Slots | PCIe Slot 1: 1 x8 with x8 bandwidth, Half Length, Low Profile Slot 2: 1 x16 with x8 bandwidth, Half Length, Low Profile One dedicated PCIe x8 slot on the system board for internal PERC |
| Chassis | Fans Up to 4 fans |
| Bezel | Security Bezel Optional Filter Bezel |
| Form Factor | 1U rack server |
| Dimensions & Weight | Height 1.68 inches (42.8 mm) Width 18.97 inches (482.0 mm) Depth 22.18 inches (563.3 mm) Weight 29.17 lbs. (13.23 kg)maximum weight |
| Rack Support | Stab-in sliding rails with optional cable management arm (CMA) for 4-post racks. |
| Recommended Support | Choose Dell ProSupport Plus or Dell ProSupport for premium hardware and software support. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region. For more information, visitwww.delltechnologies.com/Services. |
| Processor | One Intel®Xeon®6300 series processor or one Intel®Xeon®E-2400 series processor with up to 8 cores or One Intel®Pentium®G7400/ G7400T processor with 2 cores |
| Operating System | Canonical®Ubuntu®Server LTS Microsoft®Windows Server®with Hyper-V RedHat®Enterprise Linux SUSE®Linux Enterprise Server VMware®ESXi® |
| Chipset | Intel®C262 Chipset |
| Accelerators | NA |
| Memory | DIMM Speed Up to 4400 MT/s Memory Type ECC UDIMM Memory Module Slots 4 DDR5 DIMM slots Maximum RAM ECC UDIMM 128 GB |
| Storage | Front Bay Up to 4 x 3.5’’ SAS/SATA HDD/SSD, max 64 TB Up to 8 x 2.5’’ SAS/SATA HDD/SSD, max 61.44 TB Up to 6 x 2.5″ SAS/SATA HDD/SSD+2 x 2.5″ NVMe, max 61.44 TB Note: NVMe doesn’t support S160 or HW RAID configuration. Mid Bay NA Rear Bay NA |
| Storage Controllers | Internal Controllers HBA355i Adpt, PERC H355 Adpt, PERC H755 Adpt, HBA355i front, H355 front, H755 front External Controllers HBA355e Adpt Software RAID S160 Internal Boot Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs USB |
| Security | Cryptographically signed firmware Data at Rest Encryption (SEDs with local or external key mgmt) Secure Boot Secure Erase Secured-core server Secured Component Verification (Hardware integrity check) Silicon Root of Trust System Lockdown (requires iDRAC9 Enterprise or Datacenter) TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ |
| Management | Embedded / At-the-Server: iDRAC9 iDRAC Direct iDRAC RESTful API with Redfish iDRAC Service Module Consoles: OpenManage Enterprise OpenManage Power Manager plugin OpenManage Service plugin OpenManage Update Manager plugin CloudIQ for PowerEdge plug in OpenManage Enterprise Integration for VMware®vCenter™ OpenManage Integration for Microsoft®System Center OpenManage Integration with Windows Admin Center Mobility: OpenManage Mobile Tools: Dell Repository Manager Dell System Update Enterprise Catalogs iDRAC RESTful API with Redfish IPMI RACADM CLI OpenManage Integrations: BMC Truesight Microsoft®System Center OpenManage Integration with ServiceNow RedHat®Ansible®Modules Terraform Providers VMware®vCenter™ and vRealize Operations Manager |
| Power Supplies | 600 W Platinum 100 — 240 VAC or 240 VDC, hot swap redundant 700 W Titanium 200 — 240 VAC or 240 VDC, hot swap redundant |
| Ports | Network Options 2 x 1GbE LOM Front Ports 2 x 1GbE LOM 1 x iDRAC Direct (Micro-AB USB) port 1 x USB 2.0 Rear Ports 1 x Dedicated iDRAC Ethernet port 1 x USB 2.0 1 x USB 3.2 Gen1 1 x VGA 1 x Serial Internal Ports 1 x USB 3.2 Gen1 |
| Slots | PCIe Slot 1: 1 x8 with x8 bandwidth, Half Length, Low Profile Slot 2: 1 x16 with x8 bandwidth, Half Length, Low Profile One dedicated PCIe x8 slot on the system board for internal PERC |
| Chassis | Fans Up to 4 fans |
| Bezel | Security Bezel Optional Filter Bezel |
| Form Factor | 1U rack server |
| Dimensions & Weight | Height 1.68 inches (42.8 mm) Width 18.97 inches (482.0 mm) Depth 22.18 inches (563.3 mm) Weight 29.17 lbs. (13.23 kg)maximum weight |
| Rack Support | Stab-in sliding rails with optional cable management arm (CMA) for 4-post racks. |
| Recommended Support | Choose Dell ProSupport Plus or Dell ProSupport for premium hardware and software support. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region. For more information, visitwww.delltechnologies.com/Services. |
