Fujitsu PRIMERGY TX2550 M7

The enhanced dual-socket calculator and high bandwidth DDR5 processor help to improve efficiency and increase performance while reducing power consumption. The TX2550 M7 is capable of handling a range of different tasks at the highest level: demanding industrial and analytical applications, business processes and enterprise applications, and virtualised workloads.

Pretul afisat contine TVA (21%).

PRIMERGY TX2550 M7

Key Features

Power packed performance across workloads

Highly expandable and flexible design

Storage suitable for securely managing extremely large datasets and flexible enough to be matched to a range of storage centric requirements such as IT infrastructure or collaboration workloads. Drives and RAID controllers can be tailored to specific business needs and budgets. Powerful and cost-effective networking options are available depending on your business need and budget.

Designed to be upgrade ready and efficient

Versatile PCIe slots offer flexible expandability for the integration of existing and new storage controllers, networking cards, or the benefits of graphics cards. Add capabilities per your business needs. Graphics card improves performance for graphic intensive apps; get more from your display infrastructure. The server is designed for quiet operation and offers best-in-class reliability and energy efficiency with up to 96% efficiency and dual power supplies. The rack upgrade kit allows you to invest in a system designed for scalability to match your business growth.

Server and infrastructure management at your fingertips

The onboard iRMC S6, is optimized for both data centers and SMEs who can rely on the latest generation server management. With ISM centralize the data center management as well as power and cooling by using a single user interface. Improve the whole data center productivity with converged infrastructure management. M.2 devices are perfect for hassle-free hypervisor /operating system start-up, while TPM 2.0 provides ease of mind for administrators with the latest hardware and Software driven security features.

Specifications

Chipset	Intel® C741
Mainboard Type	D3985-A
Product Type	Dual Socket Tower Server
Processor	Intel® Xeon® Bronze 3xxx processor, Intel® Xeon® Silver 4xxx processor, Intel® Xeon® Gold 5xxx processor, Intel® Xeon® Gold 6xxx processor, Intel® Xeon® Platinum 8xxx processor
Memory	16 GB – 4.0 TB, DIMM (DDR5)
Memory slots	16 (8 DIMMs per CPU, 8 channels with one DIMM per channel)
Memory Protection	ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support
Drives (optional)	CD-RW / DVD Combo, ultraslim, SATA III DVD-ROM, ultraslim, SATA III LTO9HH Ultrium, 300 MB/s, 18 TB, SAS 12Gb/s DVD supermulti, ultraslim, SATA I Blu-ray Disc™ Triple Writer, ultraslim, SATA I LTO8HH Ultrium, 300 MB/s, 12 TB, SAS 6Gb/s
PCI-Express 4.0 x8	8 x Full height Note: Refer to Slot Notes.
PCI-Express 4.0 x16	4 x Full height Note: Refer to Slot Notes.
Accessible Drive Bays	3 x 5.25/1.6-inch
Optional Accessible Drives	3x 1.6×5.25″ bays for an optical and/or backup drives All possible options described in relevant system configurator.
Storage Drive Bays	3.5-inch or 2.5-inch hot-plug SAS/SATA 8 x 2.5-inch hot-plug SAS/SATA 8 x 3.5-inch hot-plug SAS/SATA 24 x 2.5-inch hot-plug SAS/SATA 4 x 3.5-inch hot-plug SAS/SATA Optional expandable up to 24 storage drives Optional expanderble up to 12 storage drives optional expanderble up to 32 storage drives not expandable optional expandable up to 8 storage drives optional expandable up to 12 storage drives optional expandable up to 24 storage drives optional expandable up to 32 storage drives
LAN Controller	2 x 1 Gbit/s onboard
Remote Management	IPMI 2.0 compatible, Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller)
USB ports	7 x USB 3.1 Gen1(USB3.0) (2x front, 4 x rear, 1x USB 3.1 Gen1 for backup devices)
Graphics	1 x VGA(1 x rear, 1 x front(Optional))
Management LAN (RJ-45)	Management LAN traffic can be switched to shared onboard LAN port, 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s)
Trusted Platform Module (TPM)	optional TPM
Power Supply Configuration	1x non hot-plug power supply or 2x hot-plug power supply for redundancy or 2x non hot-plug power supply
Active Power (max. configuration)	2,758 W
Weight	Up to 41.9 kg
Rack (W x D x H)	483 (Bezel); 448 mm (body) x 772 x 175 mm
Floor-stand (W x D x H)	177 x 776 x 456 mm
DC Infrastructure Management	Infrastructure Manager (ISM) Essential Edition Advanced Edition
Server Management	ServerView Agentless Service (SVAS), ServerView ESXi CIM Provider, ServerView Installation Manager (SVIM), ServerView Update Manager Express (UME)
Operating system	https://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
Manufacturer warranty period	3 years
Manufacturer warranty type	Onsite warranty Warranty conditions tbd
Service Lifecycle	at least 5 years after shipment, for details see https://support.eu.fsastech.com/
Service Weblink	https://eu.fsastech.com/eu/products-services/infrastructure-services/product-related-services/
Support Pack Options	Globally available in major metropolitan areas: 9×5, Next Business Day Onsite Response Time 9×5, 4h Onsite Response Time (depending on country) 24×7, 4h Onsite Response Time (depending on country)
Recommended Service	24×7 Onsite Service with 4h Onsite Response Time

SKU: fujitsu-primergy-tx2550-m7 Categorii: BRAND, FUJITSU, PRIMERGY Servers, Server&Storage

Chipset	Intel® C741
Mainboard Type	D3985-A
Product Type	Dual Socket Tower Server
Processor	Intel® Xeon® Bronze 3xxx processor, Intel® Xeon® Silver 4xxx processor, Intel® Xeon® Gold 5xxx processor, Intel® Xeon® Gold 6xxx processor, Intel® Xeon® Platinum 8xxx processor
Memory	16 GB – 4.0 TB, DIMM (DDR5)
Memory slots	16 (8 DIMMs per CPU, 8 channels with one DIMM per channel)
Memory Protection	ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support
Drives (optional)	CD-RW / DVD Combo, ultraslim, SATA III DVD-ROM, ultraslim, SATA III LTO9HH Ultrium, 300 MB/s, 18 TB, SAS 12Gb/s DVD supermulti, ultraslim, SATA I Blu-ray Disc™ Triple Writer, ultraslim, SATA I LTO8HH Ultrium, 300 MB/s, 12 TB, SAS 6Gb/s
PCI-Express 4.0 x8	8 x Full height Note: Refer to Slot Notes.
PCI-Express 4.0 x16	4 x Full height Note: Refer to Slot Notes.
Accessible Drive Bays	3 x 5.25/1.6-inch
Optional Accessible Drives	3x 1.6×5.25″ bays for an optical and/or backup drives All possible options described in relevant system configurator.
Storage Drive Bays	3.5-inch or 2.5-inch hot-plug SAS/SATA 8 x 2.5-inch hot-plug SAS/SATA 8 x 3.5-inch hot-plug SAS/SATA 24 x 2.5-inch hot-plug SAS/SATA 4 x 3.5-inch hot-plug SAS/SATA Optional expandable up to 24 storage drives Optional expanderble up to 12 storage drives optional expanderble up to 32 storage drives not expandable optional expandable up to 8 storage drives optional expandable up to 12 storage drives optional expandable up to 24 storage drives optional expandable up to 32 storage drives
LAN Controller	2 x 1 Gbit/s onboard
Remote Management	IPMI 2.0 compatible, Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller)
USB ports	7 x USB 3.1 Gen1(USB3.0) (2x front, 4 x rear, 1x USB 3.1 Gen1 for backup devices)
Graphics	1 x VGA(1 x rear, 1 x front(Optional))
Management LAN (RJ-45)	Management LAN traffic can be switched to shared onboard LAN port, 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s)
Trusted Platform Module (TPM)	optional TPM
Power Supply Configuration	1x non hot-plug power supply or 2x hot-plug power supply for redundancy or 2x non hot-plug power supply
Active Power (max. configuration)	2,758 W
Weight	Up to 41.9 kg
Rack (W x D x H)	483 (Bezel); 448 mm (body) x 772 x 175 mm
Floor-stand (W x D x H)	177 x 776 x 456 mm
DC Infrastructure Management	Infrastructure Manager (ISM) Essential Edition Advanced Edition
Server Management	ServerView Agentless Service (SVAS), ServerView ESXi CIM Provider, ServerView Installation Manager (SVIM), ServerView Update Manager Express (UME)
Operating system	https://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
Manufacturer warranty period	3 years
Manufacturer warranty type	Onsite warranty Warranty conditions tbd
Service Lifecycle	at least 5 years after shipment, for details see https://support.eu.fsastech.com/
Service Weblink	https://eu.fsastech.com/eu/products-services/infrastructure-services/product-related-services/
Support Pack Options	Globally available in major metropolitan areas: 9×5, Next Business Day Onsite Response Time 9×5, 4h Onsite Response Time (depending on country) 24×7, 4h Onsite Response Time (depending on country)
Recommended Service	24×7 Onsite Service with 4h Onsite Response Time
