ASUS RS723Q-E11-RS24

Favorite
Compara

2U4N high density server powered by 5th Gen Intel Xeon Scalable processors that designed for liquid cooling solutions and support up to dual 350W processors, 24 storage, 16 DIMMs, 3PCIe 5.0 slots, 8 NVMe, and One 1G LAN per node

Pretul afisat contine TVA (21%).

RS723Q-E11-RS24

2U4N high density server powered by 5th Gen Intel Xeon Scalable processors that designed for liquid cooling solutions and support up to dual 350W processors, 24 storage, 16 DIMMs, 3PCIe 5.0 slots, 8 NVMe, and One 1G LAN per node

Key Features

  • Powerful performance: Powered by 5th Gen Intel® Xeon® Scalable processors unleash up to 21%-greater general-purpose performance per watt, significantly improving AI inference and training
  • Scale-out infrastructure: The four-node architecture design features 24 storages bays with 8 x 2.5″ SATA/SAS/NVMe + 16 x 2.5″ SATA/SAS
  • Direct liquid cooling (DLC): Fully designed for cooling integration and installation, including CPU with higher TDP to increase data center efficiency and power density
  • Scale-up node design: Each node supports for dual processors, 16 DIMMs, 8 NVMe, two PCIe 5.0 x16 slots, two M.2, and One 1G LAN
  • High power efficiency: Redundant 3600W or 3000W Titanium power supplies
  • Enhanced IT-infrastructure management: ASUS ASMB11-iKVM remote control with ASPEED AST2600, ASUS Control Center IT management software and hardware-level Root-of-Trust solution

Specifications

Processor / System Bus
  • Per node:
  • 2 x Socket P (LGA 4677)
  • 4th Gen Intel® Xeon® Scalable processors
  • 5th Gen Intel® Xeon® Scalable processors
  • (with Liquid cool up to 350WU)
Generation
  • E11
Core Logic
  • Intel® C741
Memory
  • Per node:
  • 16 x DIMM slots
  • 4th: DDR5 4800 MHz RDIMM/3DS RDIMM (1DPC)
  • 5th: DDR5 5600/4800 MHz RDIMM/3DS RDIMM (1DPC)
  • 512GB, 256GB, 128GB Intel® Optane™ persistent memory 300 series
Expansion Slots
  • Per node:
  • up to 3 slots
  • 1 x PCI-E x16 (Gen5 x16 link), LP (HHHL)
  • 1 x PCI-E x8 (Gen5 x8 link), LP (HHHL), optional
  • 1 x OCP 3.0 Mezzanine (Gen5 x16 link)
Storage
  • Per node:
  • SAS/SATA Controller :
  • LSI 3008 8-port SAS 12G Controller (Option)
HDD Bays
  • 24 x 2.5″ Front Hot-swap drive bays
  • (Up to 8 x NVMe/SATA/SAS + 16 x SATA/SAS supported)*
  • Per node:
  • 2 x M.2  (Up to 22110, SATA or Gen4 x2 link)
  • * Converter Board with SAS 3008 is required to support RAID and SATA/SAS
  • hard drives
Networking
  • Per node:
  • 1 x Intel i210
  • 1 x Management Port
Graphic
  • Aspeed AST2600 with 64MB VRAM
Rear I/O Ports
  • Per Node:
  • 1 x USB 3.1 Gen1 ports
  • 1 x mini Display port
  • 1 x RJ-45 1GbE LAN ports
  • 1 x RJ-45 Mgmt LAN port
Switch/LED
  • Per Node:
  • Front:
  • – 1 x Power Switch/LED
  • – 1 x Location Switch/LED
  • – 1 x Message LED
  • – 2 x LAN LED
  • Rear:
  • – 1 x Power Switch/LED
OS Support
  • Please find the latest OS support from https://servers.asus.com/support/os
Management Solution
  • Optional ASUS Control Center Enterprise
  • On-Board ASMB11-iKVM
Dimensions
  • 890mm x 444mm x 88mm
  • 35.04″ x 17.48″ x 3.46″
Form Factor
  • 2U
Weight
  • Net Weight: 37.50 kg
  • Gross Weight: 40.50 kg
Power Supply
  • 1+1 Redundant 3000W 80 PLUS Titanium Power Supply
  • Rating: 220-240 Vac, 15.5A (x2), 50-60Hz, Class I
  • 1+1 Redundant 3600W 80 PLUS Titanium Power Supply
  • 220V-240Vac, 10A (X2), 50HZ-60HZ, Class I
  • * 1+1 Redundant mode only supports CPUs under 205W
Note
  • 1. For the full function of the system, please install both CPUs on each node.
  • 2. Certain high TDP CPUs may be supported only with specific conditions. Please contact ASUS Technical Support for additional information and Thermal solution about specialized system optimization.
Environment
  • Operation temperature: 10℃ ~ 35℃
  • Non operation temperature: -40℃ ~ 70℃
  • Non operation humidity: 20% ~ 90% (Non condensing)
SKU: rs723q-e11-rs24 Categorii: , , , ,
Processor / System Bus
  • Per node:
  • 2 x Socket P (LGA 4677)
  • 4th Gen Intel® Xeon® Scalable processors
  • 5th Gen Intel® Xeon® Scalable processors
  • (with Liquid cool up to 350WU)
Generation
  • E11
Core Logic
  • Intel® C741
Memory
  • Per node:
  • 16 x DIMM slots
  • 4th: DDR5 4800 MHz RDIMM/3DS RDIMM (1DPC)
  • 5th: DDR5 5600/4800 MHz RDIMM/3DS RDIMM (1DPC)
  • 512GB, 256GB, 128GB Intel® Optaneâ„¢ persistent memory 300 series
Expansion Slots
  • Per node:
  • up to 3 slots
  • 1 x PCI-E x16 (Gen5 x16 link), LP (HHHL)
  • 1 x PCI-E x8 (Gen5 x8 link), LP (HHHL), optional
  • 1 x OCP 3.0 Mezzanine (Gen5 x16 link)
Storage
  • Per node:
  • SAS/SATA Controller :
  • LSI 3008 8-port SAS 12G Controller (Option)
HDD Bays
  • 24 x 2.5″ Front Hot-swap drive bays
  • (Up to 8 x NVMe/SATA/SAS + 16 x SATA/SAS supported)*
  • Per node:
  • 2 x M.2  (Up to 22110, SATA or Gen4 x2 link)
  • * Converter Board with SAS 3008 is required to support RAID and SATA/SAS
  • hard drives
Networking
  • Per node:
  • 1 x Intel i210
  • 1 x Management Port
Graphic
  • Aspeed AST2600 with 64MB VRAM
Rear I/O Ports
  • Per Node:
  • 1 x USB 3.1 Gen1 ports
  • 1 x mini Display port
  • 1 x RJ-45 1GbE LAN ports
  • 1 x RJ-45 Mgmt LAN port
Switch/LED
  • Per Node:
  • Front:
  • – 1 x Power Switch/LED
  • – 1 x Location Switch/LED
  • – 1 x Message LED
  • – 2 x LAN LED
  • Rear:
  • – 1 x Power Switch/LED
OS Support
  • Please find the latest OS support from https://servers.asus.com/support/os
Management Solution
  • Optional ASUS Control Center Enterprise
  • On-Board ASMB11-iKVM
Dimensions
  • 890mm x 444mm x 88mm
  • 35.04″ x 17.48″ x 3.46″
Form Factor
  • 2U
Weight
  • Net Weight: 37.50 kg
  • Gross Weight: 40.50 kg
Power Supply
  • 1+1 Redundant 3000W 80 PLUS Titanium Power Supply
  • Rating: 220-240 Vac, 15.5A (x2), 50-60Hz, Class I
  • 1+1 Redundant 3600W 80 PLUS Titanium Power Supply
  • 220V-240Vac, 10A (X2), 50HZ-60HZ, Class I
  • * 1+1 Redundant mode only supports CPUs under 205W
Note
  • 1. For the full function of the system, please install both CPUs on each node.
  • 2. Certain high TDP CPUs may be supported only with specific conditions. Please contact ASUS Technical Support for additional information and Thermal solution about specialized system optimization.
Environment
  • Operation temperature: 10℃ ~ 35℃
  • Non operation temperature: -40℃ ~ 70℃
  • Non operation humidity: 20% ~ 90% (Non condensing)
