- One 5th Generation AMD EPYC™ Series processor
- Up to 12x TruDDR5 DIMM slots 6400MHz memory
- Up to 16x EDSFF drives for high performance storage
- Up to 5x PCIe 4.0 slots and, up to 2x PCIe 5.0 slots for I/O flexibility
- Up to 4x Single-width GPUs for graphics-intensive workloads
- ThinkShield Security peace of mind throughout the entire lifecycle of the server
Specifications
| Form Factor | 1U rack / 778mm (30.6″) |
| Processor | One 4th Generation AMD EPYC™ Processors or 5th Generation AMD EPYC™ Processors |
| Memory | 12x TruDDR5 DIMM slots (1DPC) Maximum 1.5TB using 128GB 3DS RDIMMsUp to 1DPC at 6400MHz |
| Drive Bays | Up to 12x 2.5″ hot-swap drive bays (hot-swap combinations – SAS/SATA, NVMe, or AnyBay™)Up to 16x EDSFFBoot Drives:2x 7mm drives at the rearInternal M.2 module supporting up to two M.2 drives |
| GPU Support | Up to 4x single-width GPUs |
| RAID Support | Hardware RAIDHBAs |
| Power Supply | Dual Redundant AC & DC supplies with Titanium/Platinum (ErP Lot9 Compliance) |
| Network Interface | OCP 3.0 mezz adapter; 1GbE Dedicated Management, optional 2nd port using OCP slot |
| Slots | Up to 5x PCIe 4.0 slots, up to 2x PCIe 5.0 slots; Up to 64x lanes via onboard NVMe connectors |
| Ports | Front:Front operator panel or Integrated diagnostic panelUSB 3.1 (USB 10 Gbps)USB 2.0 with XCC connection for mobile deviceOptional: External Diagnostic Handset via external diagnostic portOptional: VGA portRear:3x USB 3.1 ports (USB 10 Gbps)VGA portSystem ID LEDError LEDNMI buttonOptional: Serial (COM) port |
| Systems Management | ThinkSystem XClarity Controller (based on AST2600)Optional: Root of Trust (RoT) module with TPM 2.0 |
| Operating Systems | Microsoft Windows ServerSUSE Linux Enterprise ServerRed Hat Enterprise LinuxVMware vSphere |
| Limited Warranty | 1- and 3-year customer replaceable unit and onsite service, next business day 9×5; optional service upgrades |
