Dell PowerEdge XE9712
Rack-scale server system purpose-built for the future of AI, delivering unmatched performance and scalability to drive the next generation of AI models.
PowerEdge XE9712
Rack-scale server system purpose-built for the future of AI, delivering unmatched performance and scalability to drive the next generation of AI models.
Key Features
Redefining AI infrastructure
Rack-scale server system purpose-built for the future of AI, delivering unmatched performance and scalability to drive the next generation of AI models.
Specifications
| Processor | Two NVIDIA Grace with 72 cores per processor |
| Operating System | Grace OS |
| Accelerators | 4 Blackwell Ultra GPU’s 900GB/s of coherent memory through NVLINK CPU-GPU interconnect |
| Memory | DIMM Speed Up to 5200 MT/s Memory Type LP DDR5X memory with error-correction code (ECC) Memory Module Slots NA Maximum RAM • 480 GB of LP DDR5 memory with error-correction code (ECC) / CPU • 288 GB HBM3e / GPU |
| Storage | Front Bays Up to 8 x EDSFF E1.S hot-swappable NVMe drives |
| Storage Controllers | Boot Drives 1 x M.2 Boot |
| Management | Embedded Aspeed AST2600 BMC DC-SCI compatible OpenBMC |
| Power Supplies | IR9048 rack consists of Power Shelf 33kW (PS33) that supports 6 x 5500 W AC PSUs PS33 supplies up to 54 VDC to the XE9712 through Power bus bar located on IR9048 rack Fans Eight standard cooling fans Cooling specifications Air cooling Direct Liquid Cooling (DLC) |
| Ports | Network Options 1x 1GbE LOM Front Ports 1x USB3 1x RJ45 Mgmt LAN 1x miniDP 1x USB2.0 Micro Type-B 1x 1Gb LOM |
| Slots | PCIe Up to 2 x FH HL Gen5, front risers only 2 x Mezzanine – Gen5/Gen6 PCIe Cards 1 x BF3 SuperNIC Full Height Half Length |
| Form Factor | IR9048 is a 48 RU (Rack Units) rack Each XE9712 sled is 1 RU Note: 1 RU = 1.75 in. (44.45 mm) height, and 9 in.(438 mm) width. |
| Dimensions & Weight | Height 90.3″ (2294 mm) Width 29.52″ (750 mm) Depth 47.24″ (1200 mm) 57.75″ (1340 mm) with stablizers Cabinet wet weight 3505.35 pounds (1590 kg) |
| Rack Support | IR9048 is a 48 RU (Rack Units) rack Each XE9712 sled is 1 RU Note: 1 RU = 1.75″ (44.45 mm) height, and 19″ (482.6 mm) width. |
| Recommended Support | Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region. |
| Regulatory | Product Safety, EMC and Environmental Datasheets Dell Regulatory Compliance Home Page Dell and the Environment |
| Processor | Two NVIDIA Grace with 72 cores per processor |
| Operating System | Grace OS |
| Accelerators | 4 Blackwell Ultra GPU’s 900GB/s of coherent memory through NVLINK CPU-GPU interconnect |
| Memory | DIMM Speed Up to 5200 MT/s Memory Type LP DDR5X memory with error-correction code (ECC) Memory Module Slots NA Maximum RAM • 480 GB of LP DDR5 memory with error-correction code (ECC) / CPU • 288 GB HBM3e / GPU |
| Storage | Front Bays Up to 8 x EDSFF E1.S hot-swappable NVMe drives |
| Storage Controllers | Boot Drives 1 x M.2 Boot |
| Management | Embedded Aspeed AST2600 BMC DC-SCI compatible OpenBMC |
| Power Supplies | IR9048 rack consists of Power Shelf 33kW (PS33) that supports 6 x 5500 W AC PSUs PS33 supplies up to 54 VDC to the XE9712 through Power bus bar located on IR9048 rack Fans Eight standard cooling fans Cooling specifications Air cooling Direct Liquid Cooling (DLC) |
| Ports | Network Options 1x 1GbE LOM Front Ports 1x USB3 1x RJ45 Mgmt LAN 1x miniDP 1x USB2.0 Micro Type-B 1x 1Gb LOM |
| Slots | PCIe Up to 2 x FH HL Gen5, front risers only 2 x Mezzanine – Gen5/Gen6 PCIe Cards 1 x BF3 SuperNIC Full Height Half Length |
| Form Factor | IR9048 is a 48 RU (Rack Units) rack Each XE9712 sled is 1 RU Note: 1 RU = 1.75 in. (44.45 mm) height, and 9 in.(438 mm) width. |
| Dimensions & Weight | Height 90.3″ (2294 mm) Width 29.52″ (750 mm) Depth 47.24″ (1200 mm) 57.75″ (1340 mm) with stablizers Cabinet wet weight 3505.35 pounds (1590 kg) |
| Rack Support | IR9048 is a 48 RU (Rack Units) rack Each XE9712 sled is 1 RU Note: 1 RU = 1.75″ (44.45 mm) height, and 19″ (482.6 mm) width. |
| Recommended Support | Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region. |
| Regulatory | Product Safety, EMC and Environmental Datasheets Dell Regulatory Compliance Home Page Dell and the Environment |
