Specifications
| Form Factor/Height | 2U Rack Server |
| Processor | 4x second-generation Intel Xeon Processor Scalable family CPUs, up to 205W |
| Memory | Up to 15TB in 48x slots using 24x 128GB DIMMs and 24x 512GB Intel Optane DC Persistent Memory |
| Expansion Slots | Up to 8x PCIe (with four x16) plus 1x LOM; optional 1x ML2 slot and LOM |
| Internal Storage | Up to 16x 2.5″ storage bays supporting SAS/SATA HDD and SSDs or up to 8x 2.5″ NVMe SSD; plus up to 2x mirrored M.2 boot |
| Network Interface | Multiple options with 1GbE, 10GbE, 25GbE, 40GbE , 100GbE or InfiniBand PCIe adapters; one (2-/4-port) 1GbE or 10GbE LOM card |
| Power Supply | 2x hot-swap/redundant: 750W/1100W/1600W/2000W AC 80 PLUS Platinum |
| Security and Availability Features | Lenovo ThinkShield, TPM 1.2/2.0; PFA; hot-swap/redundant drives, fans, and PSUs; internal light path diagnostic LEDs; front-access diagnostics via dedicated USB port; diagnostic LCD panel |
| RAID Support | HW RAID (up to 16 ports) with flash cache; up to 16 ports using SAS HBAs |
| Systems Management | XClarity Controller embedded management, XClarity Administrator centralized infrastructure delivery, XClarity Integrator plugins, and XClarity Energy Manager centralized server power management |
| Operating Systems Supported | Microsoft Windows Server, RHEL, SLES, VMware vSphere. Visit lenovopress.com/osig for more information.. |
| Limited Warranty | 1-year and 3-year customer replaceable unit and onsite service, next business day 9×5; optional service upgrades |
