Dell PowerEdge XE9785L

Favorite
Compara

Redefine AI performance with liquid cooling, high-density compute, and flexible power—built for the demands of your data center.

Pretul afisat contine TVA (21%).

PowerEdge XE9785L

Redefine AI performance with liquid cooling, high-density compute, and flexible power—built for the demands of your data center.

Key Features

Flexible, advanced liquid cooling servers

Redefine AI performance with liquid cooling, high-density compute, and flexible power—built for the demands of your data center.

Specifications

Processor Two 5th Generation AMD EPYC 9005 Series processors with up to 192 cores per processor
Operating System Canonical Ubuntu Server LTS
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
Accelerators 8 x AMD Instinct™ MI355X 288GB 1400W OAM with AMD Infinity Fabric connectivity
8 x NVIDIA HGX B300 1200W SXM7 GPUs, fully interconnected with NVIDIA NVLink technology
Memory DIMM Speed
Up to 6400 MT/s
Memory Type
RDIMM
Memory Module Slots
24 DDR5 DIMM slots
Maximum RAM
RDIMM 6 TB max
Storage Controllers Internal Controllers
N/A
Internal Boot
Embedded BOSS: HWRAID 0/1, 2 x M.2 NVMe SSDs
Security Cryptographically signed firmware
Data at Rest Encryption (SEDs with local or external key mgmt)
Secure Boot
Secured Component Verification (Hardware integrity check)
Secure Erase
Silicon Root of Trust
System Lockdown
Soldered down TPM on HPM board
Chassis Intrusion Detection
AMD Secure Memory Encryption (SME)
AMD Secure Encrypted Virtualization (SEV)
Management Embedded / At-the-Server
iDRAC10
iDRAC Direct
iDRAC RESTful API with Redfish
RACADM CLI
iDRAC Service Module
Consoles
OpenManage Enterprise (OME)
OME Power Manager
OME Services
OME Update Manager
OME APEX AIOps Observability
Tools
IPMI
OpenManage Integrations
Red Hat Ansible Modules
Terraform Providers
Power Supplies 33 kW Power Shelf: Comprised of 6x 5500W AC PSUs
Cooling Options
Liquid cooled-direct-to-chip CPUs and GPUs
Ports Network Options
1 x OCP NIC card 3.0 (x16 PCIe lanes)
Front Ports
1 x USB 3.0
1 x Mini-DisplayPort
1 x USB 2.0 Type – C port
2 x RJ45 dedicated iDRAC Ethernet port
Note: All front ports are located on the FIO (front I/O) board
Rear Ports
N/A
Internal Ports
1 x USB 3.0
Slots PCIe
Up to 8 x16 Gen5 PCIe full-heigh, half length slots for E-W traffic
Up to 4 x16 Gen5 PCIe full-height, half-length slots for N-S traffic
Bezel N/A
Form Factor IR7000 = 44 OU (Open Rack Units)
3OU compute node
Note: 1 OU = 48 mm (1.88 inch) height, and 538.98 mm (21.22 inch) width.
Dimensions & Weight Height
5.53 inches (140.5 mm)
Width
21.14 inches (537 mm)
Depth
41.26 inches (1047.95 mm) with fan
35.03 inches (889.65 mm) without fan
Weight
209.44 pounds (95 kg)
Rack Support Static rail for ORv3 rack
Recommended Support Choose Dell ProSupport Plus or Dell ProSupport for premium hardware and software support. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region. For more information, visitwww.delltechnologies.com/Services.
