Fujitsu PRIMERGY RX2540 M8
Fujitsu PRIMERGY RX2540 M8 - imagine 2
Fujitsu PRIMERGY RX2540 M8 - imagine 3
Fujitsu PRIMERGY RX2540 M8 - imagine 4
, , , Configureaza acest server →

Fujitsu PRIMERGY RX2540 M8

Favorite
Compara

2U, dual-socket platform that provides scalability and performance to adapt to a variety of applications. Drive demanding workloads by Intel® Xeon® 6 Processors with P-cores, supporting up to 86 P-cores per CPU.

Pretul afisat contine TVA (21%).

PRIMERGY RX2540 M8

2U, dual-socket platform that provides scalability and performance to adapt to a variety of applications. Drive demanding workloads by Intel® Xeon® 6 Processors with P-cores, supporting up to 86 P-cores per CPU.

Key Features

Reliable scalability and performance

2U, dual-socket platform that provides scalability and performance to adapt to a variety of applications. Drive demanding workloads by Intel® Xeon® 6 Processors with P-cores, supporting up to 86 P-cores per CPU.

Accelerate IT transformation

Transform your data center for modern operations and drive demanding workloads with 32 DIMM modules (up to 8TB). With DDR5 DIMM or MRDIMM memory for fast throughput and high-capacity memory for memory-intensive workloads.

Extensive expandability

Maximize storage performance with 12x 3.5″ or up to 24x 2.5″ storage devices and ensure application performance scales to meet demands. Up to 8x PCIe 5.0 slots, OCP v3 adapters, and support for 2x M.2 hot plug modules also ensure enough growth opportunities.

Focus on environmental sustainability

Reduce power consumption and operational costs with hot-plug 80+ Titanium PSUs and optimized cooling. Featuring configuration-specific Entry or Performance fans for efficient heat dissipation – enabling organizations to move to more sustainable data centers without compromising performance.

Specifications

Mainboard Type
  • D4135
Product Type
  • Dual Socket Rack Server
Processor
  • Intel® Xeon® 6500P processors, Intel® Xeon® 6700P processors
Memory
  • 16 GB – 8 TB, RDIMM (DDR5)
  • MRDIMM
Memory slots
  • 32 (16 DIMMs per CPU, 8 channels with 2 slots per channel)
Memory Protection
  • ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support
Drives (optional)
  • LTO9HH Ultrium, 300 MB/s, 18 TB, SAS 12Gb/s
  • DVD supermulti, ultraslim, SATA I
  • LTO8HH Ultrium, 300 MB/s, 12 TB, SAS 6Gb/s
Accessible Drive Bays
  • 1 x 5.25/9.5mm for DVD-RW/Blu-ray
Optional Accessible Drives
  • hot-plug M.2 carrier module
  • ODD 5.25″ possible
  • ODD 5.25″ NOT possible
  • not available on 12x 3.5†or 24x 2.5†drive base units – consult the system configurator for details
Storage Drive Bays
  • up to 8x 2.5-inch, 16x 2.5-inch, 24x 2.5-inch, 12x 3.5-inch base units
  • 8 x 2.5-inch hot-plug SAS/SATA/PCIe
  • 12 x 3.5-inch hot-plug SAS/SATA
  • 16 x 2.5-inch hot-plug SAS/SATA/PCIe
  • 24 x 2.5-inch hot-plug SAS/SATA
  • 24 x 2.5-inch hot-plug SAS/SATA/PCIe
LAN Controller
  • 1 x 1 Gbit/s onboard, Dynamic LoM via OCP slot; OCPv3 compliant, Optional OCP adapters:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP28, 4 x 25 Gbit/s SFP28, 2x 100 Gbit/s QSFP28
Remote Management
  • Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller)
USB ports
  • 5 x USB 3.2 Gen1x1 (5Gbit/s) (1x front, 2x rear, 2x internal)
Graphics
  • 2 x DisplayPort 1.1a
  • 1x rear
  • 1x front (not available on 12x 3.5″ or 24x 2.5″ drive base units)
Management LAN (RJ-45)
  • 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s)
Trusted Platform Module (TPM)
  • Infineon / TPM 2.0 module, FIPS; TCG compliant (option)
Power Supply Configuration
  • 1 x hot-plug power supply or 2 x hot-plug power supply for redundancy
Active Power (max. configuration)
  • 4,584 W
Weight
  • max. 35.6 kg
Rack (W x D x H)
  • 482 mm (Bezel) / 435 mm (Body) x 770 x 87 mm
Mounting Depth Rack
  • 779 mm
DC Infrastructure Management
  • Infrastructure Manager (ISM)
  • Essential Edition
  • Advanced Edition
Server Management
  • ServerView Agentless Service (SVAS), ServerView ESXi CIM Provider, ServerView Installation Manager (SVIM), ServerView Update Manager Express (UME)
Operating system
  • https://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
Manufacturer warranty period
  • 3 years
Manufacturer warranty type
  • Onsite warranty
Service Lifecycle
  • at least 5 years after shipment, for details see https://support.eu.fsastech.com/
Service Weblink
  • https://eu.fsastech.com/eu/products-services/infrastructure-services/product-related-services/
Recommended Service
  • 24×7 Onsite Service with 4h Onsite Response Time
SKU: fujitsu-primergy-rx2540-m8 Categorii: , , ,
Mainboard Type
  • D4135
Product Type
  • Dual Socket Rack Server
Processor
  • Intel® Xeon® 6500P processors, Intel® Xeon® 6700P processors
Memory
  • 16 GB – 8 TB, RDIMM (DDR5)
  • MRDIMM
Memory slots
  • 32 (16 DIMMs per CPU, 8 channels with 2 slots per channel)
Memory Protection
  • ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support
Drives (optional)
  • LTO9HH Ultrium, 300 MB/s, 18 TB, SAS 12Gb/s
  • DVD supermulti, ultraslim, SATA I
  • LTO8HH Ultrium, 300 MB/s, 12 TB, SAS 6Gb/s
Accessible Drive Bays
  • 1 x 5.25/9.5mm for DVD-RW/Blu-ray
Optional Accessible Drives
  • hot-plug M.2 carrier module
  • ODD 5.25″ possible
  • ODD 5.25″ NOT possible
  • not available on 12x 3.5†or 24x 2.5†drive base units – consult the system configurator for details
Storage Drive Bays
  • up to 8x 2.5-inch, 16x 2.5-inch, 24x 2.5-inch, 12x 3.5-inch base units
  • 8 x 2.5-inch hot-plug SAS/SATA/PCIe
  • 12 x 3.5-inch hot-plug SAS/SATA
  • 16 x 2.5-inch hot-plug SAS/SATA/PCIe
  • 24 x 2.5-inch hot-plug SAS/SATA
  • 24 x 2.5-inch hot-plug SAS/SATA/PCIe
LAN Controller
  • 1 x 1 Gbit/s onboard, Dynamic LoM via OCP slot; OCPv3 compliant, Optional OCP adapters:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP28, 4 x 25 Gbit/s SFP28, 2x 100 Gbit/s QSFP28
Remote Management
  • Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller)
USB ports
  • 5 x USB 3.2 Gen1x1 (5Gbit/s) (1x front, 2x rear, 2x internal)
Graphics
  • 2 x DisplayPort 1.1a
  • 1x rear
  • 1x front (not available on 12x 3.5″ or 24x 2.5″ drive base units)
Management LAN (RJ-45)
  • 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s)
Trusted Platform Module (TPM)
  • Infineon / TPM 2.0 module, FIPS; TCG compliant (option)
Power Supply Configuration
  • 1 x hot-plug power supply or 2 x hot-plug power supply for redundancy
Active Power (max. configuration)
  • 4,584 W
Weight
  • max. 35.6 kg
Rack (W x D x H)
  • 482 mm (Bezel) / 435 mm (Body) x 770 x 87 mm
Mounting Depth Rack
  • 779 mm
DC Infrastructure Management
  • Infrastructure Manager (ISM)
  • Essential Edition
  • Advanced Edition
Server Management
  • ServerView Agentless Service (SVAS), ServerView ESXi CIM Provider, ServerView Installation Manager (SVIM), ServerView Update Manager Express (UME)
Operating system
  • https://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
Manufacturer warranty period
  • 3 years
Manufacturer warranty type
  • Onsite warranty
Service Lifecycle
  • at least 5 years after shipment, for details see https://support.eu.fsastech.com/
Service Weblink
  • https://eu.fsastech.com/eu/products-services/infrastructure-services/product-related-services/
Recommended Service
  • 24×7 Onsite Service with 4h Onsite Response Time
